24-way automatic wire selector up to 6 mm²
Select & Distribute
Automatic wire and cable selector
WireFlow 40
WireFlow 40 is an automatic wire and cable selector designed to optimise wiring production lines. Able to manage up to 40 automated ways for cross-sections from 1.5 mm² to 35 mm², this unit eliminates 100% of selection errors while providing an ultra-fast cycle time of less than 2 seconds without stopping production.
Are you looking for similar equipment?
Technical specifications
The WireFlow 40 is a state-of-the-art industrial unit dedicated to the automated selection and management of wires and cables. It integrates perfectly into an existing production line or a Mecaspin line. With capacity for 40 automated ways, it provides automatic reference changes in masked time (cycle time below 2 seconds), considerably reducing downtime and standardising productivity between different operators.
Reliability and performance
Designed to guarantee the highest level of quality, WireFlow 40 provides 100% selection reliability, preventing reference inversions or operator errors during the manufacturing process. It handles wire and cable cross-sections from 1.5 mm² to 35 mm², with a configurable ejection length from 10 cm to 5 metres.
Automated operating procedure
Its operation is based on a fully automated process:
- Automatic reading of the production file.
- Automatic rewinding of wires ejected during the sequence.
- Automatic ejection of the new wires to be used.
- Automatic rewinding at the end of production.
Technical information
| Number of ways | 40 |
| Permitted wire and cable cross-sections | 1.5 mm² to 35 mm² |
| Dimensions (L × D × H) | 1,350 × 960 × 1,790 mm |
| Selection reliability | 100% |
| Length of ejected wires | Configurable from 10 cm to 5 m |
| Machine compatibility | Mecaspin or existing line |
| Electrical supply | 230 V single-phase 50 Hz |
| Pneumatic supply | 6 bar |
| Rated single-phase power | 1 kW |
| Communication | Bus, Ethernet |
Key benefits
01. Standalone – 40 automated ways
Automatic selection of wire and cable references. Compatible with cross-sections from 1.5 mm² to 35 mm². Operates on a Mecaspin production line or can be integrated into an existing line.
02. Reliable – 0% selection errors
Eliminates reference inversions in production. Secures and standardises processes. Eliminates differences in error rates between operators.
03. Fast – Cycle time < 2 s
Automatic reference changes without stopping production. Changes take place in masked time. Reduces productivity differences between operators.
